• Data Guard
  این تکنولوژی راهکاری نرم‌افزاری برای تهیه نسخه پشتیبان بین دو دستگاه مجزا می‌باشد. با استفاده از تکنولوژی Data Guard می‌توان داده‌های نقطۀ اول (برای مثال RAID و External Storage) و دوم (Thecus NAS) را با رابط کاربری آسان و مدیریت کاربر پسند، همسان‌سازی نمود.

• Data Burn
  بدون هیچ زحمتی، امکان نوشتن اطلاعات به صورت مستقیم بر روی DVD ،CD و Blu-ray محیا شده است. اين ماژول قابلیت ساخت مدیا از روی فایل‌های ISO، صوتی و متنی را با سرعت بالا و همزمان با کارکرد عادی دستگاه را داراست.

• ضد ویروس
  کلیه محصولات ما با مشارکت آنتی ویروس قدرتمند McAfee، کلیه اطلاعات ذخیره شده بر روی خود را به طور منظم و مستمر در برابر تهديدات ناشی از بدافزارها محافظت می‌کنند. این امکان هزینه جداگانه‌ای برای مشتریان Thecus نخواهد داشت.

• Cloud Backup
  علاوه بر امكان ذخيره‌سازی اطلاعات با تکیه بر تکنولوژی RAID، می‌توان داده‌ها را به سادگی و بصورت Drag and Drop در محیط‌های ابری همانند DropBox و Amazon S3 و ElephantDrive قرار داد تا براحتی بتوان در هر مكان و شرايطی به آنها دسترسی داشت.

• خروجی HDMI
  به راحتی می‌توان از طریق خروجی HDMI که توسط این دستگاه پشتیبانی می‌شود، تلویزیون را بصورت مستقیم به دستگاه متصل نمود.



• اتصالات USB 3.0
  نسل جدید ارتباط (USB 3.0) با سرعتی 10 برابر سریعتر از USB 2.0 توسط این محصول پشتیبانی می‌شود که می‌توان انواع تجهیزات از قبیل دوربین دیجیتال، تلفن‌های هوشمند، هاردهای اکسترنال و ... را با استفاده از این تکنولوژی به دستگاه متصل نمود و از سرعت بالای این فناوری در کنار تکنولوژی‌های قدیمی‌تر (USB 2.0, USB 1.1) استفاده کرد.

• Acronis True Image
  Thecus با مشارکت کمپانی Acronis و تکیه بر نرم‌افزار تهیه نسخه پشتیبان True Image با محیطی ساده و کاربر پسند، این امکان را فراهم می‌کند تا فقط با یک کلیک از فایل های مهم خود نسخه پشتیبان تهیه کنید.

• RAID چندگانه
  Thecus این امکان را فراهم می‌کند تا با استفاده از انواع RAID ها نظیر (0، 1، 5، 6، 10، 50، 60 و JBOD) بتوانید از داده‌های خود محافظت کنید. در صورت عملکرد نادرست و یا معیوب شدن یکی از دیسک‌ها، به سرعت هارد معیوب جایگزین شده و اطلاعات بازنویسی می‌گردند.

• فایل سیستم چندگانه
  پشتیبانی از فایل سیستم های مختلف (EXT3, EXT4, XFS) باعث انعطاف‌پذیری سیستم می‌شود و این امکان را فراهم می‌کند تا کاربر به راحتی در محیط‌های مختلف بصورت همزمان به اطلاعات خود دسترسی پیدا کند.



• iSCSI Thin-Provisioning
  با استفاده از این تکنولوژی در کنار سرعت فوق العاده iSCSI می‌توان از فضاهای ذخیره‌سازی خالی موجود به صورت Thin-Provision استفاده نمود و بهره‌وری کلی سیستم در استفاده از منابع را بهبود بخشید.

• اتصالات iOS/Android
  در دنیای جدید دستیابی به اطلاعات از هرجایی جزو مهمترین موضوعات می‌باشد. شما می‌توانید با استفاده از T-OnTheGo و T-Dashboard کلیه اطلاعات را از طریق اتصالات مبتنی بر سیستم عامل‌های iOS/Android ارسال و دریافت نمایید و یا حتی به مدیریت دستگاه NAS بپردازید.

• Rsync
  این تکنولوژی امکان پشتیبان‌گیری از راه دور را مبتنی بر سیستم عامل لینوکس ارائه می‌نماید.

• User Quota
  برای مدیریت آسان فضای دیسک‌ها بر روی NAS، می‌توان فضای ذخیره‌‌سازی را میان کاربران تقسیم نمود و به هر کاربر سهم مورد نیاز خود را اختصاص داد.



•

Overview

Time marches ever on, and Thecus® is ready to keep pace with its latest revision to the award winning SMB 4-bay rackmount line: the N4510U PRO. With a nearly 15% rise in processing speed thanks to the Intel® Atom^™ D2701 processor and a stylish new front panel, the new N4510U PRO can begin future-proofing your business this November.

Product highlights

-Intel® Atom^™ D2701 Dual-Core Processor (2.13GHz)
-2GB DDR3 RAM
-Redesigned front panel
-HDMI and VGA output
-Choice of single or redundant power supply
-Six USB ports (including two USB3.0)
-FREE McAfee Antivirus included
-FREE Acronis True Image license
-VMWare ready
-iSCSI thin-provisioning supported

“Data usage has been increasing exponentially for years,” explains Florence Shih, General Manager of Thecus®. “And with this growth comes not only the need for greater storage, but also the need for more powerful processing power from storage devices. So when businesses decide to invest in IT infrastructure, they look not only at capacity, but also at a device’s ability to serve users and offer features to improve efficiency and effectiveness within the workplace. With our update of the N4510U, we’re offering business professionals our already comprehensive feature set and module database, as well as a timely upgrade to underlying hardware. This is the unique combination that keeps Thecus users ready for whatever the future holds.”

Case studies

Doris, the CEO of a design startup, has watched as her dreams became reality and then some. Starting out small with renovations and interior design projects for friends and family, she found her approach of revitalizing the past to be a hit. The word spread and now she found herself at the head of 20 employees expanding to new premises in a month. Given the continuing growth of her business and the storage needs of hundreds of large Photoshop files, Doris has decided to invest in a rack system. Because of the N4510U Pro’s vast array of software (such as Data Burn, which allows Doris to conveniently burn copies of her designs onto discs for clients, and a free copy of Acronis True image, for storing her employees work securely on her home NAS) and hardware features (for example the HDMI output, which means easy design sharing on the office HDTV), she confidently commits to her first of three Thecus® rackmounts.

It’s coming to the end of the year and Michelle, an IT specialist, needs to improve the performance of her network with a limited budget. She’s sure she could get the performance she needs out of an Intel® Core^™ powered NAS, but the economical goals set by her manager don’t allow for it. After reading some positive review of its predecessor, Michelle decides to add another Thecus® NAS to her company’s IT infrastructure. She knows that with the N4510U PRO’s iSCSI Thin-Provisioning, overheads will be kept low, there will be reduced energy consumption and heat generation, and that all the while she’ll be clocking in higher data transfer speeds. Thanks the unit’s VMWare certification, Michelle can also make the most of virtualization technology. Through this, she can ensure even greater energy efficiency, as well as improved system consolidation and simplification. And to top off all the savings Michelle has been able to make, she proudly finishes her quarterly report with a note that the system came bundled with a free copy of McAfee antivirus.

Getting the most out of your NAS

What sets Thecus® products apart from other similar devices, besides years of experience and numerous world firsts in the storage industry, are the modules (apps) that expand the functionality and extend the applicability of their NAS. Since the recent unveiling of the App Center this August, Thecus® has consolidated a database of over 200 frequently updated official and third-party modules. By sharing nearly double the number of modules as their nearest competitors, Thecus® users can be sure that they’re getting a device with growing versatility and continued relevance in an ever-changing world.

Introducing the new N4510U PRO

Thanks to its proud history, the new N4510U PRO brings with it a proven feature set. Now with a brand new heart, this trusted workhorse is ready to carry your business into 2014 and beyond.

Specs

1. Hardware Platform

Item	Spec
Processor	Intel® Atom™ D2701 (2.13GHz Dual Core)
System Memory	2GB DDR3
LAN Interface (PCI-e)	RJ-45x2 : 10/100/1000 BASE-TX Auto MDI/MDI-X WOL supported
USB Interface	USB 2.0 host port x4 (back x4)  USB 3.0 host port x2 (front x2)
LCM Module	LCM display 4 buttons (ENTER, ESC, UP, DOWN)
HDMI Output	HDMI port (back x1)
VGA Output	VGA port (back x1)
Audio	MIC input, Line input, Audio output
Disk Interface	4 x SATA for internal 1 x eSATA for external
Power Supply	200W Power Supply (N4510U PRO-S), 250W Redundant power supply (N4510U PRO-R)
Thermal/Fan control	Thermal sensor on processor temperature
System Clock	Battery-backed up system clock
Power Management	Auto power on after shutdown due to power loss
Buzzer	Adjustable frequency alarm
Buttons	Power button LCM button Locator button Mute button while system alert System reset button (Hardware)
Environment	Temperature: 5°C to 40°C Humidity: 0 ~ 80 % R.H. (Non-condensing)
Chassis	4bays 1U Rack Mount
Dimensions (HxWxD)	N4510U PRO-S: 44 x 432.5 x 492 (mm)/ 1.73 x 17.03 x 19.37 (in) N4510U PRO-R: 44 x 432.5 x 552 (mm)/ 1.73 x 17.03 x 21.73 (in)
Weight	N4510U PRO-S:8.8(Kgs)/19.4(lb)(NAS only) N4510U PRO-R:10.9(Kgs)/24.03(lb)(NAS only)
Certificates	CE/FCC/C-Tick/VCCI/BSMI RoHS WEEE

2. Software Functions

RAID
RAID Modes	RAID 0, 1, 5, 6, 10 and JBOD
Auto-rebuild	Supported
Hot-swap	Supported
Hot Spare	Supported
Online RAID Migration	Supported
Online RAID Expansion	Supported
RAID Volume Encryption	AES256bit
Disk
Power Management	Available spin-down on idle setting
Bad Block Scanning	Supported
SMART Info	Supported
SMART Test	Supported
Disk Roaming	Supports volume-based roaming to other Thecus NAS
Network
Configuration	Fixed IP address, dynamic IP address
Transport Protocols	TCP/IP/AppleTalk
File Protocols	SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP
Link Aggregation	Load balance, Failover, 802.3ad, Balance-XOR, Balance-TLB, Balance-ALB, Broadcast
TCP/IP	IPV6 & IPV4
DDNS	Supported
SSH	Supported
UPnP	Supported
UPnP Port forwarding	Supported
System status
System Monitor	Monitoring CPU, memory, network utilization and protocols access user count
Syslog Management	Send syslog to assigned location Act as syslog server to receive log info from other systems
Data Access
Client OS Support	Windows XP and after Windows Server 2003 and after UNIX/Linux Mac OS X
FTP	Built-in FTP server with bandwidth control
Secure FTP	Built-in secure FTP server with bandwidth control
TFTP	Users can download and upload files with TFTP programs
Download Manager	BT download (via Transmission module) NZB download (via NZB module)
Printer Server (IPP)	Supports USB printers Supports a wide range of IPP printers Client can manage print tasks  (list/delete) via web user interface
Data Backup
Client Incremental Data Backup	Acronis True Image (OEM version)
Client System Disaster Recovery	Acronis True Image (OEM version)
Client Side Backup Software	Thecus Backup Utility (Windows/Mac OS X)
Data Burn	Create files to ISO image and burn to optical disc Create files to ISO image Read ISO image from optical disc and write to NAS
Mac OS X Time Machine	Supported
Data Guard	Remote Backup/Local Backup
Block Level Access
iSCSI Target/Initiator	Supports Microsoft/Mac OS X/Linux initiators and Thecus NAS targets
iSCSI Thin Provisioning	Supported
MPIO	Supported
MCS	Supported
Clustering	Supported
SCSI3 Persistent Group Reservation	Supported
Power Management
Scheduled Power On/Off	Supported
Volume Management
Multiple RAID	Supported
Multiple File System Selectable	EXT3/EXT4/XFS
Multimedia Support
iTunes Server	Supports AAC, MP3 w/ID3 tag and WAV
Piczza!™ Photo Server (via module)	Supports GIF, JPG (JPEG), BMP and PNG Supports EXIF display Supports slide shows
Media Server	Supports uPnP AV streaming protocol
User Authentication
Local User	Supports built-in user accounts
Local Group	Supports built-in user groups
Windows ADS	Supported
LDAP	Supported
Access Guard	Supports Black & White list/IP Filter
Cloud Backup
DropBox	Supported (via module)
ElephantDriver	Supported (via module)
Amazon S3	Supported
File System
Type	Journaling File System
Language Support	Unicode Support
Authorization (ACL)	“Read”, “write”, or “deny” privileges to individual users or groups in folders and sub-folders
User Quota	Supported
Administration
User Interface	Web-based user interface supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, Russian, Polish, Portuguese.
Utility Program	MS Windows Setup Wizard Supports Windows XP and after Windows Server 2003 and after Mac OS X Setup Wizard
Email Notifications	Sends system messages via email to the system administrator
SNMP Trap	System information trap out
Mobile Applications (iOS/Android)
T- Dashboard™	Mobile monitoring and administration (via module)
T-OnTheGo™	Upload, download and stream multimedia
Data Security
Virus Scan	Supports McAfee® (via module)
Capacity Expansion
Stackable	Can extend for 5 additional iSCSI volumes from other Thecus NAS
Others
Recycle Bin	Supported
Web Disk	Supported (via module)
Web Server	Supported (via module)
ISO Mount	Supported
IP Cam Surveillance	Supports up to 5 IP cameras (via module)
Auto Module Installation	Thecus’ module server automatically provides the latest modules and updates through the user interface.
Local Display	X-Window via HDMI output
