N2310
N2310 Best-in-Class Value
  • RAID support (0, 1, and JBOD)
  • Web-based file access
  • Built-in FTP server
  • BitTorrent client
  • Plex Media support
  • Mobile control and media streaming via T-OnTheGo™ (for Android and iOS)
  • Easy Connection Through DDNS** (How-to)
  • 5 minute complete installation
  • Self-RAID creation
  • Energy Efficient: 5W without HDD(about 14W with 2 HDD loaded)


Awards/Reviews

2014-07-18
Media: MegaObzor | Country: Russia
Thecus® N2310 Receives ‘Editor’s Choice’ Award from MegaObzor, RU
“The Thecus N2310 is an example of the right approach to creating a home NAS”
In the end, MegaObzor stressed N2310’s “performance level, which is enough sufficient for a local storage device.” As a result, “the Thecus N2310 is awarded with the well-deserved gold Editor’s Choice award from MegaObzor.com.”
2014-07-16
Media: eTeknix | Country: UK
Thecus® N2310 Reviewed by eTeknix, UK
“A feather-weight champion in its class”

So what does it all boil down to? “Ultimately the performance for the price is where we will be most interested.” This happens to be where the N2310 excels. At a fraction of the price of many 2-bay NAS units on the market today, the N2310 provides “respectable performance” that is “surprisingly stronger than expected.”

2014-07-11
Media: Jeff Gedgaud | Country: USA
Thecus® N2310 Reviewed by Jeff Gedgaud, US
“I highly recommend the Thecus N2310 for a small business or home network”

Finishing off with a recommendation, Jeff awarded the Thecus N2310 4 out of 5 Stars!

2014-07-07
Media: IT Expert | Country: Russia
Thecus® N2310 Reviewed by IT Expert, RU
“A good purchase for the home and office”

Finally, the cost and value were very important factors that IT Expert also considered. “Even though the device is one of the cheapest on the market in its class, the results of the review turned out to be very good.”

2014-06-27
Media: Gear Diary | Country: USA
Thecus® N2310 Highly Recommended by Gear Diary, US
“A Fantastic Entry Level NAS”

In a nutshell, “there are just so many options, settings, features, and functions built into the N2310 that it’s a really compelling entry-level NAS option. I would highly recommend the Thecus N2310 to anyone who is in the market for a budget NAS system.”

Features

  • 5 Minute Complete Installation
    دستگاه N2310 با هدف كاربری و راهبری ساده طراحی شده، دستگاه مذكور اين امكان را به كاربر می‌دهد تا پس از اتصال برق و كابل‌های شبكه در مدت 5 دقيقه بتوان پيكربندی را انجام داده و شروع به استفاده از آن نمائيد.
  • Self-RAID Creation
    كليه دستگاه‌های Thecus مجهز به ابزارهای خودكار مديريت و تحليل فعاليت ديسک سخت می‌باشند كه می‌توان نسبت به ايجاد خودكار ساختار RAID اقدام كرد.
  • T-OnTheGo™ Mobile App
    با استفاده از اين ابزار مديريتی می‌توان از طريق تلفن‌های هوشمند (iOS & Android) به كليه اطلاعات موجود بر روی دستگاه Thecus دسترسی كامل داشت. همچنين بر روی بستر شبكه‌های ابری می‌توان از هر جايی از طريق اينترنت اين عمليات را انجام داد.
  • DDNS
    با استفاده از اين قابليت كاربران می‌توانند با استفاده از نام‌های DNS با آدرس IPهای گوناگون به راحتی به فايل‌های خود دسترسی داشته باشند و محدوديت‌های تغيير در آدرس IP مانع دسترسی از راه اينترنت نخواهد شد.
  • PLEX Media Center
    برنامه Plex Media به عنوان المان اصلی هر سيستم صوتی تصويری مطرح می‌‌باشد. اين نرم افزار قابل استفاده در دستگاه Thecus می‌‌باشد. با اجرای اين برنامه می‌توان به تجهيزا ت گوناگون تحت شبكه و موبايل متصل شد و نسبت به پخش تصاوير اقدام كرد.
  • Native BitTorrent Support
    در نسخه 6 سيستم عامل ThecusOS نسخه كاربری نرم افزار BitTorrent وجود دارد. با استفاده از اين برنامه می‌توان فايل‌های قابل دانلود از راه P2P را بر روی دستگاه ذخيره كرد و استفاده نمود.
  • Data Guard
    این تکنولوژی راهکاری نرم‌افزاری برای تهیه نسخه پشتیبان بین دو دستگاه مجزا می‌باشد. با استفاده از تکنولوژی Data Guard می‌توان داده‌های نقطۀ اول (برای مثال RAID و External Storage) و دوم (Thecus NAS) را با رابط کاربری آسان و مدیریت کاربر پسند، همسان‌سازی نمود.
  • Data Burn
    بدون هیچ زحمتی، امکان نوشتن اطلاعات به صورت مستقیم بر روی DVD ،CD و Blu-ray محیا شده است. اين ماژول قابلیت ساخت مدیا از روی فایل‌های ISO، صوتی و متنی را با سرعت بالا و همزمان با کارکرد عادی دستگاه را داراست.
  • USB 3.0 Connectivityاتصالات USB 3.0
    نسل جدید ارتباط (USB 3.0) با سرعتی 10 برابر سریعتر از USB 2.0 توسط این محصول پشتیبانی می‌شود که می‌توان انواع تجهیزات از قبیل دوربین دیجیتال، تلفن‌های هوشمند، هاردهای اکسترنال و ... را با استفاده از این تکنولوژی به دستگاه متصل نمود و از سرعت بالای این فناوری در کنار تکنولوژی‌های قدیمی‌تر (USB 2.0, USB 1.1) استفاده کرد.
  • User Quota User Quota
    برای مدیریت آسان فضای دیسک‌ها بر روی NAS، می‌توان فضای ذخیره‌‌سازی را میان کاربران تقسیم نمود و به هر کاربر سهم مورد نیاز خود را اختصاص داد.

Overview

Just in time for Christmas, Thecus® is announcing the release of its latest home and SOHO NAS, the N2310. Equipped with an Advanced Micro Circuits Corporation (AMCC) 800MHz SoC processor and 512MB of DDR3 RAM, this latest 2-bay device is a great choice for those seeking solid storage solutions on a budget.

My little black number

Though not as powerful as the N2560 and N4560 released earlier this quarter, the N2310 still packs in a lot of the features of its pricier siblings:

-RAID support (0, 1, and JBOD)
-Web-based file access
-Built-in FTP server
-BitTorrent client
-Plex Media support
-Mobile control and media streaming via T-OnTheGo™ (for Android and iOS)
-5 minute complete installation
-Self-RAID creation
-Energy Efficient: 5W

Well equipped for a connected life, the N2310 not only offers users access and control of their files over the Internet, but is also able to stream stored media to Android and iOS mobile devices. And if you’re one for sharing and downloading files online, just drop the seed files into the N2310’s BitTorrent client and watch as this little NAS does the rest.

But what about the setup? That’s where our Intelligent NAS utility comes in. Once you’ve connected your N2310 to your home network, simply download and run Intelligent NAS. It’ll automatically find your NAS and allow you to easily set up your RAID or JBOD volume. Once up and running, Intelligent NAS will also allow you to effortlessly connect to the N2310’s operating system, ThecusOS™ 6, where you can monitor, configure, and update your NAS and modules.

So besides the comprehensive features and great usability, what else makes the N2310 great for home and SOHO users? Well, when we mentioned that it was a budget friendly NAS, we weren’t only referring to its cost price. The N2310’s AMCC processor and advanced design allow for such a degree of energy efficiency that its day-to-day running costs are near negligible.

“Not only does the N2310 pack in a lot of the capabilities of larger and more expensive units, but it does so with style,” noted Florence Shih, General Manager at Thecus®, proudly. “This dashing little black box can store up to 8TB of data with an unprecedented level of energy efficiency. In fact, we calculated it, and powering the N2310 for an entire year, say in the US, would only cost you $5.03.”

Featuring the new Plex Media Server, Transmission BitTorrent client, T-OnTheGo™ mobile support, and impressive performance (over 100/80MB/s read/write), the Thecus® N2310 is the perfect choice for home and SOHO stockings this December.

Specs

1. Hardware Platform
Item Spec
Processor AMCC APM 86491 800Mhz
System Memory 512MB DDR3
LAN Interface (PCI-e) RJ-45x1: 10/100/1000 BASE-TX Auto MDI/MDI-X
USB Interface USB 2.0 host port x1 (back x1)
USB 3.0 host port x1 (back x1)
Disk Interface 2 x SATA for internal
Power Supply 40W external power adaptor
Buttons Power button
USB copy button
Reset button
Environment Temperature: 5°C to 40°C
Humidity: 0 ~ 80 % R.H. (Non-condensing)
Chassis 2bays Tower
Dimensions (HxWxD) 135 x 97 x 207 (mm)/5.33 x 3.83 x 8.14 (in)
Weight 0.8(Kgs) / 1.8(lb)(NAS only)
Certificates CE/FCC/C-Tick/VCCI/BSMI
RoHS
WEEE

2. Software Functions
RAID
RAID Modes RAID 0, 1 and JBOD
Auto-rebuild Supported
Hot-swap Supported
Disk
Bad Block Scanning Supported
SMART Info Supported
SMART Test Supported
Disk Roaming Supports volume-based roaming to other N2310
Network
Configuration Fixed IP address, dynamic IP address
Transport Protocols TCP/IP, AppleTalk
File Protocols SMB/CIFS, HTTP/HTTPS, FTP, AFP, NFS
TCP/IP IPV6 & IPV4
System status
Syslog Management Send syslog to assigned location
Act as syslog server to receive log info from other systems
Data Access
Client OS Support Windows XP and after
Windows Server 2003 and after
Mac OS X
Linux
FTP Built-in FTP server with bandwidth control
Secure FTP Built-in secure FTP server with bandwidth control
Download Manager BT Transmission
Printer Server (IPP) Supports USB printers
Supports a wide range of IPP printers
Client can manage print tasks (list/delete) via web user interface
Data Backup
Client Incremental Data Backup Thecus Backup Utility
Data Burn Create files to ISO image and burn to optical disc
Create files to ISO image
Read ISO image from optical disc and write to NAS
Mac OS X Time Machine Supported
Data Guard Remote Backup/Local Backup
Power Management
Scheduled Power On/Off Supported
Volume Management
File System EXT4
Multimedia Support
iTunes Server Supports AAC, MP3 w/ID3 tag and WAV
Piczza!™ Photo Server (via module) Supports GIF, JPG (JPEG), BMP and PNG
Supports EXIF display
Supports slide shows
Media Server Supports uPnP AV streaming protocol
User Authentication
Local User Supports built-in user accounts
Local Group Supports built-in user groups
File System
Type Journaling File System
Language Support Unicode Support
Authorization (ACL) “Read”, “write”, or “deny” privileges to individual users or groups in folders and sub-folders
User Quota Supported
Administration
User Interface Web-based user interface supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, Russian, Polish and Portuguese.
Utility Program (Intelligent NAS) MS Windows Setup Wizard
Supports Windows XP and after
Windows Server 2003 and after
Mac OS X Setup Wizard
Email Notifications Sends system messages via email to the system administrator
DDNS** Support one free DDNS registration (ex. xxx.thecuslink.com) (How-to)
UPnP and Port forwarding Support auto setting in Intranet environment
Intelligent NAS Go through defined URL for auto install (install.thecus.com)
Mobile Applications (iOS/Android)
T-Dashboard™ Mobile monitoring and administration
T-OnTheGo™ Upload, download and stream multimedia
Others
Recycle Bin Supported
Web Disk Supported
**Thecus ID & DDNS setup requirements: An ADSL or Cable modem and router (that supports configurable UPnP port forwarding or IGD).

Package Contents

Accessory Bag Ethernet Cable Power Cord Power Adaptor
QIG Warranty Card All in one DVD

NAS 101

  • Are OS6 series USB patches and tools compatible between both systems (i.e. N2310 vs N2520/ N2560/ N4520/ N4560)?

    Because the N2310 and N2520/ N2560/ N4520/ N4560 are based on differing architecture (PowerPC vs. ARM), USB patches and tools are unfortunately incompatible between the two systems.

  • Can a drive with a RAID volume and OS6 roam between an N2310 & an N2520/ N2560/ N4520/ N4560?

    Because the N2310 and N2520/ N2560/ N4520/ N4560 are based on differing architecture (PowerPC vs. ARM), drives with RAID volumes and OS6 are unfortunately unable to roam between the two systems.

  • Installing and Setup MySQL-kit

    Installation and setup guide for MySQL (open-source relational database management system) and phpMyAdmin (a free and open source tool written in PHP intended to handle the administration of MySQL with the use of a web browser).

    English
  • Installing and Setup Web Server

    • Installing Webserver module
    • Start setting up the Web Server configuration

    English

Connecting to your NAS

  • How To Guides: Piczza Photo Server

    The new Piczza photo server provides a completely new interface and many new functions. The new module makes editing, organizing, and sharing photos easier than ever.

    English
  • How to publish your NAS on the internet

    This guide will show you how to publish your NAS on the Internet, this allows you to access and configure your NAS files via the internet remotely.

    English 繁體中文
  • How to use Aria2:Downloading via your NAS

    Aria2 is a lightweight multi-protocol & multi-source command-line download utility. It supports HTTP/HTTPS, FTP, BitTorrent and Metalink. aria2 can be manipulated via built-in JSON-RPC and XMLRPC interfaces.

    English
  • How-to Guide: Transmission (BitTorrent Client)

    Transmission is a cross-platform BitTorrent client.

    English
  • How-to Guide:PLEX (Media Server)

    Plex is a media player system consisting of a player application with a 10-foot user interface and an associated media server.

    English 繁體中文
  • Installing and Using XBMC

    Appealing to a broad range of users, XBMC is an open source media center which was originally created for Xbox. Its graphical user interface (GUI) allows the user to easily browse and view videos, photos, podcasts, and music using only a few buttons.
    Currently, XBMC can be used to play almost all popular audio and video formats around directly from your hard drive. XBMC features playlist and slideshow functions, a weather forecast, and many audio visualizations.

    English

Backup and Data Security

  • Installing and Using Dropbox(Thecus® OS6)

    Before installing and using the Dropbox module, there needs to be at least one user
    account on Thecus®OS6. If you have already created a user account, please skip
    section 1.
    You will also need to have already set up a Dropbox account.

    English
  • Installing and Using McAfee

    McAfee Antivirus is the best safeguard measure to detect and prevent virus attacks. With McAfee , users can rest assure that their vital data is protected with advanced features to eliminate possible threats.

    English

Thecus TV

Thecus N2310 Unboxing

- RAID support (0, 1, and JBOD)
- Web-based file access
- Built-in FTP server
- BitTorrent client
- Plex Media support
- Mobile control and media streaming via T-OnTheGo™ (for Android and iOS)
- 5 minute complete installation
- Self-RAID creation
- Energy Efficient: 5W
