N12910SAS
N12910SAS Faster, More Reliable Enterprise Storage at the Forefront of Technology
- Enterprise Size for Enterprise Tasks
- HA System Redundancy for Perfect Operational Performance
- Real-time Remote Replication and System Disaster Recovery
- Bundled with Free Acronis Server Backup
- SATA III for Ultra-Fast Transfer Speeds
- 7 Modes of Link Aggregation for Faster Transfers
- RAID 0, 1, 5, 6, 10, 50, 60 and JBOD
- Secure Remote Access with VPN Connection
Awards/Reviews
2017-10-03
Media: IT PRO | Country: UK
“…the new OS7 firmware is a big step forward. Its best fit is with businesses that want uncomplicated NAS and IP SAN services teamed up with fast SAS3 performance at an affordable price.”
2017-09-12
Media: Simply Reviews | Country: UK
“Performance is another strong point of this appliance and its high expansion potential will allow it to keep ahead of demand. The N12910SAS is perfectly poised for SMBs that want basic, hard-performing network storage services and with a starting price of under $4K, it’s impossible to beat for value.”
Features
-
 دسترس‌پذيری بالا
برای اولین بار، کلیه اطلاعات شما بطور كامل و بدون تاخير در دسترستان می‌باشد. اين ويژگی همه اطلاعات را به طور جداگانه بر روی دو دستگاه NAS يكسان نگهداری می‌كند و درصورت بروز هرگونه رخدادی بر روی يكی از دستگاه‌ها، ديگری بدون وقفه شروع به سرويس دهی می‌كند.
-
 PLEX Media Center
The Plex Media Server is both the heart and brains for any digital media system. The free server is a module available on the Thecus® App Center that allows you to set up and manage your media. With the Plex Media Server installed on your Thecus® NAS, various devices on your network (such as your Xbox 360 and mobile devices) can connect to and stream your local and online media.
-
 Snapshot Backup
With BTRFS support, Thecus NAS users can enjoy the simplicity of snapshot backups. Through BTRFS subvolumes, snapshots of data at various time points can be manually or automatically made and just as easily later restored to rollback files or folders to previous states.
-
 Disk Clone and Wipe
Disk Clone allows users to copy the entire contents of a disk to one or many other disks while Disk Wipe allows for permanent volume data destruction.
-
 VPN Server
A VPN Server allows users to remotely access a secure network. with VPNs, businesses will be able to utilize a cost-effective, scalable and secured network infrastructure for its client base.
-
 10GbE Ready
بطور معمول مراکز داده نیاز به سطحی بالاتر از طیف سرعت ارتباطات معمول امروز دارند. شركت Thecus از تکنولوژی 10GbE بر روی کلیه محصولات خود پشتیبانی می‌کند و آماده پاسخ گویی به نیازهای امروز و فردا است.
-
 اتصالات USB 3.0
نسل جدید ارتباط (USB 3.0) با سرعتی 10 برابر سریعتر از USB 2.0 توسط این محصول پشتیبانی می‌شود که می‌توان انواع تجهیزات از قبیل دوربین دیجیتال، تلفن‌های هوشمند، هاردهای اکسترنال و ... را با استفاده از این تکنولوژی به دستگاه متصل نمود و از سرعت بالای این فناوری در کنار تکنولوژی‌های قدیمی‌تر (USB 2.0, USB 1.1) استفاده کرد.
-
 Acronis True Image
Thecus با مشارکت کمپانی Acronis و تکیه بر نرم‌افزار تهیه نسخه پشتیبان True Image با محیطی ساده و کاربر پسند، این امکان را فراهم می‌کند تا فقط با یک کلیک از فایل های مهم خود نسخه پشتیبان تهیه کنید.
-
 RAID چندگانه
Thecus این امکان را فراهم می‌کند تا با استفاده از انواع RAID ها نظیر (0، 1، 5، 6، 10، 50، 60 و JBOD) بتوانید از داده‌های خود محافظت کنید. در صورت عملکرد نادرست و یا معیوب شدن یکی از دیسک‌ها، به سرعت هارد معیوب جایگزین شده و اطلاعات بازنویسی می‌گردند.
-
 فایل سیستم چندگانه
پشتیبانی از فایل سیستم های مختلف (EXT3, EXT4, Btrfs, XFS) باعث انعطاف‌پذیری سیستم می‌شود و این امکان را فراهم می‌کند تا کاربر به راحتی در محیط‌های مختلف بصورت همزمان به اطلاعات خود دسترسی پیدا کند.
-
 iSCSI Thin-Provisioning
با استفاده از این تکنولوژی در کنار سرعت فوق العاده iSCSI می‌توان از فضاهای ذخیرهسازی خالی موجود به صورت Thin-Provision استفاده نمود و بهره‌وری کلی سیستم در استفاده از منابع را بهبود بخشید.
-
 اتصالات iOS/Android
در دنیای جدید دستیابی به اطلاعات از هرجایی جزو مهمترین موضوعات می‌باشد. شما می‌توانید با استفاده از T-OnTheGo و T-Dashboard کلیه اطلاعات را از طریق اتصالات مبتنی بر سیستم عامل‌های iOS/Android ارسال و دریافت نمایید و یا حتی به مدیریت دستگاه NAS بپردازید.
-
 Rsync
این تکنولوژی امکان پشتیبان‌گیری از راه دور را مبتنی بر سیستم عامل لینوکس ارائه می‌نماید.
-
 User Quota
برای مدیریت آسان فضای دیسک‌ها بر روی NAS، می‌توان فضای ذخیرهسازی را میان کاربران تقسیم نمود و به هر کاربر سهم مورد نیاز خود را اختصاص داد.
-
 درگاه PCI-e
این درگاه امکان استفاده از فناوری‌های نوظهور را فراهم می‌نماید. شما می‌توانید با این درگاه لذت استفاده از کارتهای شبکه 10G و کارت های آداپتور USB 3.0 را داشته باشید.
Overview
10/20/2016 - Thecus® Technology Corp. today officially launched their enterprise-class SAS-enabled NAS series, the N12910SAS and N16910SAS. These supercharged 12-bay and 16-bay network-attached storage solutions offer massive scalability, trail-blazing speed with uncompromising reliability for optimal data storage performance.
“With the launch of the N12910SAS and N16910SAS, Thecus powerfully delivers a storage solution that can expertly cater to business environments that deal with demanding data workloads. Their next generation hardware allows businesses to access their business critical data faster and with greater reliability for optimal data storage performance. ” said Florence Shih, General Manager of Thecus Technology Corp.
The N12910SAS and N16910SAS are equipped with the Intel® Skylake Xeon E3-1245 v5 3.5G Hz quad-core Processor, with 16GB (expandable to 64GB) of next generation DDR4 ECC RAM. DDR4 brings even higher performance with migration to higher speed, more robust control features while improving energy economy with reduction in memory power demand.
With native support for SAS drives, users can experience the superior HDD performance of 12G. These new models are 10GbE ready and support High Availability for system redundancy. The units also deploy Daisy Chaining technology which offers connections of up to four additional D16000s, allowing users to reach storage capacities of up to 800TB.
The NAS run on the latest ThecusOS 7.0, providing an optimized, feature-rich platform with an intuitive user interface and easy navigation. Key new features include Photo Center, Thecus App Center and File Center. ThecusOS 7.0 delivers significant advancements in productivity, flexibility, and performance.
The N12910SAS and N16910SAS from Thecus® are purposely designed to meet the demanding needs of businesses working with big data. With their accelerated processing power, they provide enterprises with a robust, ultra-fast, highly scalable and reliable storage solution. These industrial-grade rackmount NAS further deliver on Thecus' ethos of ‘empowering professionals'.
Availability: Units will be ready to be shipped at the end of October.
Specs
1.Hardware Platform
| Item |
Spec |
| Processor |
Intel® Skylake E3-1245 v5 3.5GHz Quad Core Processor + Intel C236 chipset |
| Processor Compatible with |
Intel Skylake Celeron /Pentium /Core i3_i5_i7 / XEON
**Note: For special OEM/Project only. Please contact Thecus Sales for more details |
| SAS/SATA HBA |
LSI HBA card supports 12G SAS/6G SATA |
| Daisy Chain expanson port (8644) |
Supported |
| System Memory |
16GB DDR4 ECC SDRAM shipped
Memory Module Pre-installed: 8GB x 2
Total Memory Slots: 4 |
| Memory expandable up to |
64GB Memory Compatibility List |
| LAN Interface (PCI-e) |
RJ-45x2 :Auto MDI/MDI-X
WOL supported |
| USB Interface |
USB 2.0 host port x2 (front x2)
USB 3.0 host port x4 (back x4) |
| VGA/DVI/HDMI output |
Supported |
| Audio(5+1), SPDIF |
Supported |
| K/B and Mouse (PS2) |
Supported |
| LCM |
Displays system status and information |
| LED indicator |
Power:(Blue)
System busy: (Yellow)
System alert : Redundant power or system fan failure (Red)
HDD 1-12 Activity/Fail (Green/Red) |
| Available PCI-e slots |
PCI-e x8 (x1)
PCI-e x4 (x1)
PCI-e x1 (x1) |
| Power Supply |
Redundant power supply 500W or more (80plus) |
| Disk interface |
12 x SATA/SAS for internal, support SATA II / SATA III hard disk |
| Environment |
Temperature : 0°C to 40°C (Operation)
-40°C to 70°C (Non-Operation)
Humidity : 0 ~ 80 % R.H. (Non-condensing) |
| Chassis |
2U Rack Mount |
| Dimension |
89x440x662(mm) |
2. Software Functions
| RAID |
| RAID Modes |
RAID 0, 1, 5, 6, 10, 50, 60 and JBOD |
| Auto-rebuild |
Supported |
| Hot-swap |
Supported |
| Hot Spare |
Supported |
| RAID level Migration |
Supported |
| RAID Expansion |
Supported |
| RAID Volume Encryption |
AES256bit |
| Disk |
| Power Management |
Spin-down when idle |
| Bad Block Scanning |
Supported |
| SMART Info |
Supported |
| SMART Test |
Supported |
| Disk Roaming |
Supports volume-based roaming to other Thecus NAS (require OS7 64bit) |
| Disk Security |
Supported |
| Network |
| Configuration |
Fixed IP address, dynamic IP address |
| Transport Protocols |
TCP/IP/AppleTalk |
| File Protocols |
SMB/CIFS, HTTP/HTTPS, FTP, NFS v4, AFP |
| Link Aggregation |
Load balance, Failover, 802.3ad, Balance-XOR, Balance-TLB, Balance-ALB, Broadcast |
| vLan |
Supported |
| TCP/IP |
IPV6 & IPV4 |
| DDNS |
Supported |
| SSH |
Supported |
| UPnP |
Supported |
| UPnP Port forwarding |
Supported |
| Bonjour |
Supported |
| VPN Client/Server |
Supported |
| System status |
| System Monitor |
Monitoring CPU, Memory, Temperature, fan, network utilization and protocols access user count |
| Syslog Management |
1.Send the syslog to assigned location
2.Act as syslog server to receive log info from other systems |
| Data Access |
| Client OS Support |
Windows XP and after
Windows Server 2003 and after
UNIX/Linux
Mac OS X |
| FTP |
Built-in FTP Server with bandwidth control |
| Secure FTP |
Support explicit TLS |
| TFTP |
Users can download and upload files with TFTP programs |
| Download Manager |
BitTorrent downloads (via Transmission Module)
NZB downloads (via NZB Module) |
| Printer Server (IPP) |
Supports USB printers
Supports a wide range of IPP printers
Client can manage print tasks (list/delete) via web user interface |
| WebDAV/WebDAV SSL |
Supported |
| Data Backup |
| Client Incremental Data Backup |
Acronis Server Backup |
| Client System Disaster Recovery |
Acronis Server Backup |
| Local folder/iSCSI Backup |
Supported |
| Remote folder/iSCSI Backup |
Supported |
| High Availability |
Supported |
| Mac OS X Time Machine |
Supported |
| Snapshot |
Supported |
| System failover |
Supported |
| Block Level Access |
| iSCSI Target/Initiator |
Supports Microsoft/Mac OS X/Linux initiators and Thecus NAS targets |
| iSCSI Thin Provisioning |
Supported |
| MPIO |
Supported |
| MCS |
Supported |
| Clustering |
Supported |
| SCSI3 Persistent Group Reservation |
Supported |
| Power management |
| Scheduled Power On/Off |
Supported |
| Volume management |
| Multiple RAID |
Supported |
| Multiple File System Selectable |
EXT4/XFS/Btrfs |
| Multimedia Support |
| iTunes Server |
Supports AAC, MP3 w/ ID3 tag and WAV |
| Media Server |
Supports UPnP AV streaming protocol (via Module) |
| User Authentication |
| Local User |
Supports built-in user accounts |
| Local Group |
Supports built-in user groups |
| Windows ADS |
Supported |
| LDAP |
Supported |
| Access Guard |
Supports Black & White list / IP Filter |
| User Profile |
| Photo Center |
Supported |
| File Center |
Supported |
| APP Center |
Supported |
| Surveillance Center |
Supported |
| Cloud Backup |
| DropBox |
Supported (via module) |
| Elephant Drive |
Supported (via module) |
| Amazon S3 |
Supported |
| File System |
| Type |
Journaling File System |
| Language Support |
Unicode Support |
| Authorization (ACL) |
“Read”, “write”, or “deny” privileges to individual users or groups in folders and sub-folders |
| User Quota |
Supported (exclude Btrfs) |
| Folder Quota |
Supported (btrfs only) |
| Administration |
| User Interface |
Web-based user interface supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, Russian, Polish and Portuguese |
| Utility Program |
MS Windows Setup Wizard
Supports Windows XP and after
Mac OS X Setup Wizard |
| Email Notifications |
Sends system messages via e-mail to the system administrator |
| P2P Connection |
Mail registration to connect NAS remotely |
| SNMP Trap |
Sends system information trap out |
| Mobile Applications (iOS/Android) |
| Thecus Connect™ (Android) |
Provides live up-to-date information of your NAS |
| Thecus Wizard™ |
Offers fast NAS Setup via your phone |
| T-OnTheGo™ |
Upload, download and stream multimedia |
| Orbweb.me |
Uploading, downloading, streaming multimedia and webcam via P2P connection |
| Data Security |
| Virus Scan |
Support Virus Scan |
| Capacity Expansion |
| Stackable |
Can extend for 5 additional iSCSI volumes from other Thecus NAS |
| Scale-Out |
Dynamic Volume Expansion |
| Others |
| Recycle Bin |
Supported |
| Web Server (module) |
Supported (via module) |
| ISO Mount |
Supported |
| IP Cam Surveillance (module) |
Supported via Motion Eye |
| UPS |
Supported through USB interface |
| Disk Wipe |
Supported |
| Disk Clone |
Supported |
| Local Display |
X-Window via HDMI output |
Package Contents
 |
 |
 |
 |
| Accessory Bag |
Ethernet Cable |
Power Cord |
Universal CD |
 |
 |
 |
 |
| QIG |
Warranty Card |
HDD Compatibility List Card |
Sliding Shelves |
|
|
|
